HDMI 3x1 Switcher(3D Ultra HD 4Kx2K)

1.0 TECHNICAL PARAMETER IN DETAIL

2.0 PANEL INTRODUCTION

IR Ext ------------------------------IR Receiver Extension Port

IR -------------------------------------------------IR Receiver Port

L1-L3 -----------------------------------HDMI Input1-3 Indicator

SELECT -----------------------------------Input Selector button

POWER ------------------------------------------Power Indicator

DC/5V --------------------------------------DC Power Input Port

HDMI OUTPUT ------------------------------HDMI Output Port

HDMI INPUT1-3 ------------------------------HDMI Input Ports

3.0 APPLICATION

It switches several routes HDMI signals from source device such as DVD, Satellite Receiver, Set-top Box, DV Camera, A/V Receiver and other HDMI enabled device to high definition display device such as HDTV and HDMI Flat Panel Display.

3.1 Connect high definition display device such as HDTV TO HDMI Switch's

   output port.

3.2 Connect source device such as DVD and ps3 TO HDMI Switch's input

   ports.

3.3 After all the connections have been successfully done and then power on,

  you can select the information you want to view or listen.

Note: When HDMI Switch works, make sure the source device and display device are well connected with cables. In order to make the relevant ports work properly, firstly power on switch, the power on source device.

4.0 INSTALLATION AND PRECAUTIONS

To avoid electric shock , product damage and to protect your safety , please notice the following:

Please slowly plug or unplug signal cables and do not often plug , unplug , or

 shake them.

The equipment should not be placed under the sun , rain and damp or

 unventilated environment.

3.Liquid items should not be placed on the equipment.

4.Do not install the equipment near heat sources such as fire , power , or other

 amplifiers that produce heat.

Do not insert the metal or other objects to the equipment in addition to

 connecting cables to ports.

Do not demolish the equipment by yourself ; it should be maintained by

 professional maintenance staff.
